Ozone Sterilizing & Deodorizing Machine

SKU: WAS 014

Quantity :

Loading ...
The Ozone Sterilizing & Deodorizing Machine is a compact yet powerful solution for eliminating stubborn odours and disinfecting enclosed spaces. Built with a durable 304 stainless steel chassis and a long-life honeycomb ceramic plate, it delivers a high ozone output of 5g/h to neutralize smoke, pet smells, and lingering contaminants across areas up to 120 m³. Designed exclusively for unoccupied rooms, such as offices, hotels, clinics, and homes, it ensures safe operation with a 120 minute mechanical timer, automatic shut off, and internal high voltage isolation. Weighing just 2.65 kg, this portable unit combines professional grade odour removal with reliable air purification, making it an essential tool for maintaining fresh, hygienic environments.
Share:
Ozone Sterilizing & Deodorizing Machine
Code: WAS 014
Overall Size: 279L x 170W x 253H mm
Length without Timer Knob Switch: 260 mm
Height without Handle: 213 mm
Weight: ± 2.65kg
Rated Voltage: 220V-50Hz
Rated Power: 80W
Power Source: Electric
Cable Length: 1.4m
Ozone Output: 5g/h
Sterilizing Agent: Ozone (O₃)
Operating Time: 120 minutes (max)
Machine Rest Time: 30 to 60 minutes after machine operated (Avoid overheat)
Room Waiting Time: 2 to 4 hours after machine operated (For room safety)
Gas Source: Ambient Air
Cooling Method: Air Cooling
Coverage Space: 120 m³ (max)
Effective Area Rate: 100 m² / 30 min | 1,076 sq ft / 30 min
Control Mode: Timer Knob Switch
Material (Chassis Shell): Stainless Steel 304
Material (Ozone Generating Plate): Honeycomb Ceramic Plate
Standard Packing: 1 unit x 1 carton
Remark: Always refer to the Safety Information and Blog mentioned below to prevent accidents when operating this machine.
Remark: Ozone Sterilizing & Deodorizing Machine also known as Ozone Generator, Ozone Air Filter, Fresh Air Ozone Sterilizer, Pure Zone Odour Eliminator, Air Guard Ozone Purifier, O₃ Clean Sterilizer, Odour Free Ozone Disinfection Device, Ozone Generator Purificador, Sterilize Ozone Purifier, Ozone Purifier, Ozone Generator & Air Purifier, O₃ Fresh Purifier, Clean Air Ozone Machine, and Ozone Sterilizer & Odour Eliminator.
Key Features
1. High Ozone Output: Produces 5 g/h of ozone (O₃) from ambient air using a honeycomb ceramic generating plate for powerful sterilization and deodorization.
2. Proven Disinfection Efficacy: Achieves a ≥99.90% kill rate for Staphylococcus albus and ≥90% reduction for naturally occurring airborne bacteria, fully compliant with the 2002 Disinfection Technical Specifications.
3. Generous Coverage: Suitable for spaces up to 120 m³ (max), effectively treating an area of 100 m² (1,076 sq ft) in 30 minutes.
4. Durable Construction: Chassis shell made of stainless steel 304; ozone generating plate is a long-life honeycomb ceramic type.
5. Simple Timer Control: Mechanical timer knob switch allows settings from 10 to 120 minutes, plus continuous operation, with automatic shut-off.
6. Safety-First Design: Requires grounded 220V-50Hz supply (80W rated power), includes 1.4 m cable, and features a high-voltage internal isolation for operator safety.
7. Compact & Portable Design: Weighs just 2.65 kg with a compact footprint, making it easy to relocate between spaces.
8. Wall-mount installation slot: Designed for wall or trolley mounting, easily hangs in place.

Applications
1. Unoccupied Space Disinfection & Odour Removal: Designed exclusively for sealed, unoccupied rooms. Ideal for homes, offices, hotels, clinics, beauty salons, pet areas, and vehicles (when unoccupied).
2. Air & Surface Sterilization: Effectively inactivates airborne and surface microorganisms including bacteria, viruses, and mould, while breaking down volatile organic compounds (odours).
3. Operating Environment Conditions: Use only in dry indoor areas with relative humidity below 75%. Keep a minimum 2-metre clearance from the ozone outlet to all objects to prevent discolouration of surfaces.
4. How to Operate: Place the unit in the centre of the sealed room, set the timer (max. 120 minutes per cycle), leave immediately, and allow the cycle to finish automatically.
5. Cooling Cycle: If multiple cycles are needed, allow the machine to rest for 30 to 60 minutes between operations to prevent overheating.

Care & Maintenance
1. Routine Cleaning: Perform routine cleaning of the exterior and air vents once a month. Ensure the unit is disconnected from the power supply before any maintenance.
2. High-Voltage Warning: Internal components contain high voltage. The housing must never be opened by non-qualified persons. All internal maintenance or repairs must be performed only by a professional electrician.
3. Proper Storage: After use, relocate the unit to a dry, well-ventilated area. This prevents moisture buildup from high humidity or temperatures, extending the machine's lifespan.
4. Power Cord Replacement: If the external power cord is damaged, it must be replaced with a compliant, certified cord (available from the manufacturer or qualified supplier) by authorised personnel.
5. Professional Repairs Only: The internal components contain high voltage. Do not open the housing. All internal maintenance and repairs must be handled by a qualified electrician while the unit is completely disconnected from power.

Safety Information
1. Zero Occupancy Rule: Disinfection must be carried out in a sealed room with absolutely no people, pets, or plants present.
2. Re-Entry Protocol: After the machine shuts off, wait at least 30 minutes before re-entering the room strictly to open windows for ventilation.
3. Maximum Operating Time: Do not exceed the recommended maximum operating duration of 120 minutes per cycle.
4. Cooling Requirement: Allow 30 to 60 minutes cooling time between consecutive operating cycles.
5. Room Waiting Time: For optimal safety, allow 2 to 4 hours before normal occupancy following ozone treatment, depending on room size and ventilation conditions.
6. Humidity Limitation: Operate only in environments with relative humidity below 75%.
7. Electrical Safety: Ensure the machine is properly grounded before use.
8. High Voltage Warning: The unit contains high-voltage components. Do not open the housing unless performed by qualified electrical personnel.
9. Power Off During Abnormal Conditions: Immediately disconnect the power supply if unusual noises, odours, overheating, or malfunction occur.
10. Maintain Safe Distance: Keep a minimum distance of 2 meters between the ozone outlet and surrounding objects to prevent material discoloration or damage.
11. Keep Away from Water: Do not operate the machine in wet conditions or expose it to direct water contact.
12. Use According to Instructions: Always follow the operating manual and safety guidelines to prevent injury or equipment damage.
